Navy Roll Safety Spray Shields for Marine Applications

APS Navy Spray Shields are designed to be used in engine spaces on naval and commercial vessels. The inner layer of aluminum laminated fiberglass resists heat, chemicals and moisture. The outer layer is a flame retardant silicone resistant to abrasion, flexing, tear and puncture.

In the event of a leak in a joint, this navy spray shield product temporarily contains and deflects leaks and sprays of pressurized fluids. This deflection can prevent the flammable liquid from coming into contact with hot surfaces and the dripping into electrical switch-boards or components.

Related Documents


  • Inner layer is an aluminumized laminated to fiberglass

  • Outer layer is a flame retardant silicone resistant to abrasion, flexing, tear and puncture

  • Stainless steel lacing wire

  • Meets flange standards ANSI, DNPN, and MIL-C-20079

  • Meets ASTM Designation F1138, the standard specification for spray shields for mechanical joints

  • Tensile strength: 375 psi

  • Tear strength: 55 lbs

  • Burst strength: 750 psi

  • Max temperature: 500°F (260°C)

  • Sizes available:

    • 2″ thru 8″ w x 30′ length
    • 9″ thru 16″ w x 20′ length
    • Cut to length on site

Protect your crew and engine rooms from dangerous sprays outs or leaks

with Navy Roll Safety Spray Shields by APS
